Lithophane LED Backlight Board Kit
Note: The latest version and portable photo frames are now available on MakerWorld. For more details, click here.
Introduction
Bring your images to life! By combining 3D printing technology with the PLA CMYK Lithophane Bundle, you can effortlessly design and create stunning Lithophane artworks at home. Simply use the Lithophane LED Backlight Board Kit to illuminate your creations and make them truly shine.
Start creating your lithophane with Make My Lithophane today! Make My Lithophane is also available in Bambu Handy now.
Bring colors to your lithophane
6 Litophane Styles to Choose From
Note: The latest version and portable photo frames are now available on MakerWorld, with updated supporting documents are provided below for download.
For more details, click here. We welcome everyone's feedback about the model to further improve it.
Documentation
Specification
3D ModelApplication Instruction
Basic Information
| Number of LEDs | 48/pcs |
| Connector Model | PH2.0 x 2 |
| Voltage | 5V |
| Current | 2A |
Difference between CMYK Backlight Board And This Kit
|
Product
|
|
（2PCS）
|
Lithophane LED Backlight Board
（4PCS） |
| Size support | Single size | Single size | Multiple sizes supported |
| Lithophane Size(including margin) | 144 x 108 x 2.7 mm | 2PCS：106 x 156 x （2.5-3.2）mm | 2PCS：106 x 156 x （2.5-3.2）mm OR 3PCS：156 x 156 x （2.5-3.2）mm OR 4PCS：156 x 207 x（2.5-3.2）mm |
| Assemble Methods | One | Two | Five |
| Design | Fixed size | Modular design | |
| Dimming function | Fixed | Adjustable (long-press dimming) | |
| Power cable | Not included | Inclued | |
| Ideal for | Users seeking a straightforward solution | Users who require flexibility and customization | |
| Models | Creators | Model Links |
|
xxxxDiablo Cathedral - Detailed Light-Up Miniature
|
MaKim | xxxxDiablo Cathedral - Detailed Light-Up Miniature |
|
Ozark Mountain Sunset Book Nook
|
MaKim | Ozark Mountain Sunset Book Nook |
In the Box
| Item for Lithophane LED Backlight Board Kit (2PCS) - KC009 | Qty |
|
2PCS |
|
1PCS |
|
1PCS |
| Item for Lithophane LED Backlight Board Kit (4PCS) - KC010 | Qty |
|
4PCS |
|
3PCS |
|
1PCS |
Considerations
-
Smaller nozzle sizes and lower layer heights are essential to achieve better printing results. We suggest using 0.2mm or 0.4mm nozzle sizes and layer heights between 0.08mm and 0.12mm. If you use other tools to generate the lithophane model, you may need to configure the print profile to optimize the result. Please check CMYK Lithophane Printing Guide on Wiki.
-
Due to the limitations of printing layers and resolution, there may be some color deviation between the actual image and the lithophane prints.
-
To prevent warping, the recommended heated bed temperature is between 45-50℃.
